USB-C Docking Station with MST and PD Charging from Manhattan - Drive three monitors at once with 11 connections to your device

Increase your productivity with your desktop, notebook or tablet using this highly versatile docking station from Manhattan. Its Multi-Stream Transport (MST) technology helps you to multitask on three monitors at the same time since it includes an HDMI, a DisplayPort and a VGA port. Use the HDMI and Mini DisplayPort connections for 4K@30Hz images or the VGA connection for 1080p@60Hz.

Connections to all your peripherals

With three USB ports for mice, keyboards and flash drives, a 3.5 mm stereo port for a headset and two slots for SD/microSD cards, this docking station easily satisfies all your connectivity demands. Plus, its Gigabit RJ45 port provides the wired network connection that’s missing in most modern Ultrabooks™ and MacBooks^®.

Up to 100 W charging power with USB-C Power Delivery (PD)

The included USB-C PD port lets you charge your notebook with power up to 100 W while simultaneously charging your other mobile devices, such as smartphones or tablets, through the USB-A ports. The Power Delivery function also provides faster charging than standard chargers since it determines the power needs of compatible devices and supplies it at the quickest and safest rate.

Take your phone to the big screen

Connect any Android 9 and later smartphone that supports video output over USB-C USB-C DP Alt Mode to enjoy your apps and media even more. Watch a video on your monitor or flip through the slides of your presentation - all from your phone.

A multiport adapter that's made to go where you go

Sturdy aluminum housing makes this multiport adapter the perfect travel companion. Despite its massive connectivity options, it’s still compact enough to fit right in your backpack or computer bag with your main device.

Creates a multi-display setup, charges your devices and connects all your peripherals
Dual-video output with resolutions up to 4K@30Hz, or triple-video output with resolutions up to 1080p@60Hz
Up to 4K@30Hz UHD (3840 × 2160) resolution on HDMI connection
Up to 4K@30Hz UHD (3840 × 2160) on Mini DisplayPort connection
Up to 1080p@60Hz Full HD (1920 x 1080) resolution on VGA connection
Uses Multi-Stream Transport (MST) for display modes on Windows® (Mirror or Fully Extended) and Mac® (Mirror or Extended Mirror only)
One Gigabit Ethernet (10/100/1000) port for faster downloads, media streaming and gaming
Three USB 3.2 Gen 1 Type-A ports (formerly USB 3.0) with SuperSpeed transfer rates up to 5 Gbps and charging up to 7.5 W (5 V / 1.5 A)
USB-A ports to connect mice, keyboards, flash drives and more or to charge and sync mobile devices
SD and microSD card slots with read/write function; slots support cards up to 2 TB and data transfer speeds up to 832 Mbps
Supports USB Power Delivery (PD) function up to 100 W; requires an external PD charger - available from Manhattan
3.5 mm jack for high-quality stereo sound; supports both a mic (audio input) and headphones (audio output)
Compatible with all USB-C DP-Alt-Mode-supported desktops, notebooks and tablets including Apple® MacBook®, Chromebook™, Pixel™ and more
Compliant with DisplayPort 1.2 Alternate Mode (DP Alt Mode)
Lets your smartphone work like a desktop PC while also charging it (desktop setup requires devices with Android 9 or above that offer video output over USB-C)
Can be placed below your laptop, takes up no extra space on your desk
Built-in, sturdy 20 cm (8 in.) cable with molded aluminum boot, perfect for notebooks with USB-C port on the left
Sturdy, sleek aluminum housing, great for both desktop and travel
Rubber feet to prevent slipping and to protect your desk from scratches
Plug-and-play installation; Windows®, macOS®, Linux®, Chrome OS™, and Android™ compatible
Three-year warranty

DP 1.2 Alt Mode over USB-C
USB 3.2 Gen 1
HDMI 1.4
HDCP 1.4
CE
FCC
RoHS
UKCA

General
Max. video resolutions:
- HDMI: 4K@30Hz
- Mini DisplayPort: 4K@30Hz
- VGA: 1080p@60Hz
- If two video ports are used at a time, the max. resolution per display is 4K@30Hz
- If all three video ports are used at a time, the max. resolution per display is 1080p@60Hz
USB-A ports data transfer speed: 5 Gbps
Supported flash cards: microSD, SD, SDHC and SDXC up to 2 TB
Bus powered operation (except charging functions)
USB-C PD charging port: 100.0 W (20.0 V at 5.0 A) max.
USB-A charging: 7.5 W (5.0 V at 1.5 A) max.
Audio output support: 48 kHz, 16-bit stereo

Connections
One USB-C 24-pin, male
One HDMI 19-pin, female
One Mini DisplayPort 20-pin, female
One VGA 15-pin, female
One 10/100/1000 Mbps RJ45, female
Three USB-A 4-pin, female
One SD memory slot
One microSD memory slot
One 3.5 mm stereo audio, female
One USB-C 24-pin, Power Delivery, female

Physical
Aluminum housing
Dimensions (L x W x H): 80 x 280 x 17 mm (3.15 x 11.02 x 0.67 in.)
Net weight: 245 g (0.54 lbs.)
Gross weight: 355 g (0.78 lbs.)
Cable length: 20 cm (8 in.)
Cable diameter: 34 AWG

Operating Environment
Operation temperature: 0 - 45°C (32 - 113°F)
Storage temperature: -10 - 70°C (14 - 158°F)
Humidity (noncondensing): 5 - 90% RH

System Requirements
Windows 7/8.1/10/11, Linux, Chrome OS, macOS or Android

Package Contents
USB-C PD 11-in-1 Triple-Monitor Docking Station with MST
Instructions

Additional SKUs

EAN: 0766623130578
UPC: 766623130578

Physical Specifications

Weight: 0.25 kg
Dimensions: 80 (L) x 280 (W) x 17 (H) [mm]
Packaging: Retail Box
Carton Quantity: 20
Carton Weight: 8.00 kg
