Easily add Ethernet-ready devices to your home or office network at Gigabit speeds

The Manhattan 8-Port Gigabit Ethernet Switch is perfect for home office or entertainment system use, as well as many small office applications. Small, powerful and reliable, this Gigabit Ethernet Switch is easy to install and connects up to eight Ethernet-ready devices — computers, gaming systems, network printers, media streamers, network attached storage, Smart TVs ... you name it — at speeds of up to 1000 Mbps (1 Gigabit) over standard Cat5e or Cat6 Ethernet cables.

The auto features of this switch make installation plug and play and hassle free. Plus, it has Green Ethernet technology, allowing it to monitor power usage and turn off unused ports to save electricity.

8-port Gigabit Ethernet switch expands your network in an instant
Easy plug-and-play installation — simply power it up and start using it
Eight 10/100/1000 auto-sensing ports automatically detect optimal network speeds
High performance, half and full duplex, with zero packet loss
Green Ethernet power-saving technology deactivates unused ports
Supports any combination of 10 Mbps, 100 Mbps or 1 Gbps network devices
Ultra-compact, fanless design ideal for home and office applications
Store and forward switching architecture
Three-Year Warranty

IEEE 802.3 (10Base-T Ethernet)
IEEE 802.3u (100Base-TX Fast Ethernet)
IEEE 802.3ab (Gigabit Ethernet)
IEEE 802.3x (Flow Control and Backpressure)
IEEE 802.3az (Energy Efficient Ethernet)

General
Connectors: 8 10/100/1000 Mbps RJ45 ports
Cable: Cat3, 4, 5 UTP/STP
Duplex modes: all ports (up to 200 Mbps)
Uplink: all ports Auto MDI/MDX (Auto Uplink)
Switch architecture: store and forward switch technology
Filter/forward rate:
- 10BaseT: 14,880 pps (packets per second)
- 100Base-TX: 148,800 pps (packets per second)
- 1000Base-T: 1,488,000 pps (packets per second)
MAC address table: 2,048 entries
Buffer memory: 256 kBytes
Jumbo frame support: 9 kB
Backplane speed / switch fabric: 16 Gbps
Certifications: FCC Class B, CE, RoHS

LEDs
Power
Link/Activity

Power
External AC adapter: 5 V, 1 A

Environmental
Dimensions: 65 (L) x 125 (W) x 22 (H) mm (2.56 (L) x 4.92 (W) x 0.87 (H) in.)
Weight: 0.33 kg (0.73 lbs.)
Operating temperature: 0 – 40˚C (32 – 104˚F)
Humidity: 10 – 90% (non-condensing)

Package Contents
8-Port Gigabit Ethernet Switch
Power adapter
User manual

Additional SKUs

Amazon ASIN: B00I3THTVI
EAN: 0766623560702
UPC: 766623560702
ALSO: 2154044
API: 195699

Physical Specifications

Weight: 0.33 kg
Dimensions: 65 (L) x 125 (W) x 22 (H) [mm]
Packaging: Retail Box
Carton Quantity: 50
Carton Weight: 14.00 kg

Datasheet

Datasheet » Download

Declaration of Conformity » Download

Manual

Quick Install Guide (multilanguage)
English, Deutsch, EspaÃ±ol, Polski, Italiano, FranÃ§ais » Download

Multilanguage Instructions
English, Deutsch, EspaÃ±ol, Polski, Italiano, FranÃ§ais » Download

Quick Instruction Guide » Download
