The Intellinet Network Solutions wall mount cabinets offer you a flexible and comprehensive solution for your network installations. Our service starts with the shipping condition – get the completely assembled cabinet delivered or save space and money with the flat-pack version. In terms of housing, you can choose from among the extra-compact 10″ cabinets and numerous 19″ versions, with installation depths that range from 300 to 600 mm. Heights from 6 to 20 units in black (RAL9005) or (RAL7021) & gray (RAL7035).
We offer you a solution for every need.
Various options include:
Removable side panels (some lockable).
Tempered/Toughened glass doors.
Double Section, making cabling and component exchange simple.
- Ideal for 19" rackmount applications
- Maximum static load of 60 kg
- Usable depth: 410 mm (16.14 in.)
- Tempered-glass door can be opened more than 180°
- Cable entry via rear or top panel
- Cold-rolled, galvanized SPCC steel with up to 1.2 mm thickness
- Reversible Front door
- Easily removable side panels
- Ships flatpacked
- Three-Year Warranty
- General
- 19"
- Height: 15U
- Color: Gray RAL7035
- Complies with: ANSI/EIA RS-310-D; IEC60297-2; DIN41494, Part 1; DIN41494, Part 7
Physical
- Dimensions (H x W x D): 770 x 570 x 600 mm (30.3 x 22.4 x 23.6 in.)
- Usable depth: 410 mm (16.14 in.)
- Net weight: 28 kg (61.73 lbs.)
- Gross weight: 29 kg (63.93 lbs.)
Package Contents
- 2 depth-adjustable mounting rails
- Installation hardware including tool, 20x M6 Sets and 2x Keys
There is a 2-piece set of spare rails available for this product by the model number shown:
- #712705
Additional SKUs
- Amazon ASIN: B00NYQQY48
- EAN: 0766623711968
- UPC: 766623711968
- ALSO: 2282631
- API: 155238
Physical Specifications
- Product net weight: 28 kg
- Product gross weight: 29 kg
- Dimensions: 770 x 570 x 600 (mm)
- Packaging type: Brown Box
- Packaging dimensions: 800 x 600 x 180 [mm]
- Master Carton Quantity: 1
- Master Carton Weight: 29.00 kg
- Master Carton Dimensions: 800 x 600 x 180 [mm]
