The Intellinet Network Solutions Basic 19" Network Cabinet helps secure your crucial network equipment at an excellent value. Constructed from solid steel and coated with electrostatic-powder paint, the cabinet incorporates heavy-duty, depth-adjustable mounting rails to help ensure that equipment stays secure, a safety-glass door for quick equipment-status checks as well as four cable-entry slots to keep the cabinet organized and accessible. UL and RoHS certifications further instill confidence that the Intellinet Network Solutions Basic 19" Network Cabinet is the right choice at the right price.
- Ideal for all 19 in. rackmount applications
- Maximum static load of 600 kg (1,322 lb.)
- Tempered-glass door
- Zinc-plated 19 in. mounting rails
- Antistatic powder coating on all panels
- Reversible front door
- Easily removable locking side and rear panels
- Single-point cylindrical door lock
- Cable-entry and ventilation slots
- Ships flatpacked
- Three-year warranty
- General
- 19 in.
- Height: 22U
- Color: Black RAL9005
- Certifications: RoHS, UL
Dimensions
- 800 (D) x 600 (W) x 1144 (H) [mm] / 31.5 (L) x 23.62 (W) x 45.04 (H) [in]
Package Contents
- Basic 19" Network Cabinet
- Four depth-adjustable mounting rails
- Four adjustable supporting feet
- Installation hardware
A 4-piece set of castors is available for this product by the model shown:
#712163
Additional SKUs
- EAN: 0766623715362
- UPC: 766623715362
Physical Specifications
- Product net weight: 70.7 kg
- Product gross weight: 78.5 kg
- Dimensions: 800 (L) x 600 (W) x 1144 (H) [mm]
- Packaging type: Brown Box
- Packaging dimensions: 1630 x 635 x 270 [mm]
- Master Carton Quantity: 2
- Master Carton Weight: 157.00 kg
- Master Carton Dimensions: 16300 x 5900 x 10700 [mm]
